Mini 100-240V White Split Condensate Pump, AC Hvac Silent Condensate Pump, 50/60Hz, External Wall Mount, Self Priming Device, Used for Indoor Air Conditioning, HVAC, Dehumidifier, etc.
Category: Air Conditioner Drain Pump

About this item
【Purchasing instructions】Condensing pump is micro-split, ultra-thin shape, suitable for more installation needs, with an independent pump body and water tank, the overall suspension loop, independent water storage, automatic drainage, the minimum sound is 19dB(A). Small split condensing pump is suitable for air conditioning, HVAC, dehumidifier and other equipment requiring automatic drainage professional design.
【Complete accessories】Mini split condensate pump includes pump assembly *1, anti-siphon connector * 1,150 mm/6 "length of 6mm / 1/4" i/d vinyl tube*1, fuse *1, expansion screw * 3,200 mmx5mm /12 "x 1/8" cable ties*5.
【Parameter setting】Power supply :100-240V AC, 50/60Hz; Max.flow:38L/h @ 0 head; Sound level:<19dB(A) @ 1m; Water storage: 230ml; Max.recommended head:20m; Max.unit output: 28kw / 95550 Btu/h; Safety switch:3A Normally closed Max.water temperature:70ºC; Discharge tube:6mmID; Class:II appliance; Rated:continuous; Fully potted:√; L×W×H: 164mm×70mm×102mm.
【Remote application】air conditioning drain removal pump is very simple, but it needs to be installed outside the air conditioner, fixed with expansion screws, the pump body and the liquid storage tank are integrated, whether the operation and cleaning are more convenient, a float is used to induce the water tank to drain. Equipped with professional anti-siphon device and operation manual.
【After-sales service】Ac condensate pump uses high-quality materials and is a fully enclosed electronic device that has been professionally evaluated by a professional manufacturer before leaving the factory, making it quiet and environmentally friendly. Installation has detailed professional installation instructions, you can tell me directly when you encounter problems, give you a professional and satisfactory answer, while supporting free return and exchange, your satisfaction is our pursuit.
color | White |
material | Plastic |
item_weight | 1.54 pounds |
manufacturer | Knocokie |
power_source | Corded Electric |
customer_reviews | 5.0 5.0 out of 5 stars 1 rating 5.0 out of 5 stars |
best_sellers_rank | #76,843 in Industrial & Scientific (See Top 100 in Industrial & Scientific) #15 in HVAC Condensate Pumps |
country_of_origin | China |
item_model_number | 83939 |
batteries_included | No |
batteries_required | No |
product_dimensions | 5.31 x 7.68 x 3.94 inches |
included_components | Mini split condensate pump includes pump assembly *1, anti-siphon connector * 1,150 mm/6 "length of 6mm / 1/4" i/d vinyl tube*1, fuse *1, expansion screw * 3,200 mmx5mm /12 "x 1/8" cable ties*5. |
date_first_available | June 6, 2023 |
